The 0010844150 from Molex is an MLX-series PCB power connector header, also identified by the traditional part-number format 10-84-4150. It provides 15 circuits arranged in three rows, with a 6.35mm centerline, vertical orientation, and through-hole PCB termination for multi-circuit wire-to-board interconnections.
The header uses male contacts and a natural or white PA nylon 6/6 housing rated to UL 94V-2. Its conductive terminals are manufactured from phosphor bronze, with tin plating on both the mating and termination areas for reliable electrical contact and solderability.
The official MLX product specification lists a 600V voltage rating. Six-, nine-, twelve-, and fifteen-circuit versions have a maximum current rating of 9A, while the smaller two- through four-circuit variants are rated up to 12A. Actual current capability depends on PCB construction, ambient temperature, circuit loading, and thermal conditions.
The operating-temperature range is −55°C to +105°C, including temperature rise produced by the applied current. Tin-plated versions are rated for up to 50 mating cycles. Initial low-level contact resistance is limited to 2.5mΩ, minimum initial insulation resistance is 1000MΩ, and dielectric strength is tested at 2900V AC for one minute between adjacent terminals.
The 0010844150 uses a shrouded and polarized vertical-header construction with PCB-retention features. Recommended PCB thickness is 1.57mm, and the nominal PC-tail length is approximately 4.27mm. The official drawing shows approximate overall dimensions of 33.02 × 20.32 × 13.97mm for the 15-circuit version.
The part is supplied in bag packaging. Molex’s current series page displays Check Availability, so stock, minimum packaging quantity, and lead time should be verified before procurement. Compatible MLX plug housings and terminals should be selected according to the required polarization and current rating.
Key Specifications
- Manufacturer: Molex
- Manufacturer Part Number: 0010844150
- Traditional Part Number: 10-84-4150
- Engineering Number: A-42002-15A1A1
- Product Family: MLX / 42002
- Component Type: PCB Power Connector Header
- Connector Gender: Male
- Number of Circuits: 15
- Number of Rows: 3
- Orientation: Vertical
- Mounting Type: Through-Hole
- Mating Pitch: 6.35mm
- Termination Pitch: 6.35mm
- Voltage Rating: 600V
- Maximum Current Rating: 9A
- Operating Temperature: −55°C to +105°C
- Mating Durability: Up to 50 Cycles
- Initial Contact Resistance: 2.5mΩ Maximum
- Initial Insulation Resistance: 1000MΩ Minimum
- Dielectric Strength: 2900V AC for One Minute
- Contact Material: Phosphor Bronze
- Mating Contact Plating: Tin
- Termination Plating: Tin
- Housing Material: PA Nylon 6/6
- Flammability Rating: UL 94V-2
- Housing Color: Natural / White
- Construction: Shrouded, Polarized, with PCB Retention
- Recommended PCB Thickness: 1.57mm
- PC-Tail Length: Approximately 4.27mm
- Approximate Dimensions: 33.02 × 20.32 × 13.97mm
- Net Weight: Approximately 7.726g
- Packaging: Bag
- Website Availability: Check Availability
- Compliance: RoHS Compliant
Typical Applications
Suitable for industrial equipment, power assemblies, appliances, control systems, and other applications requiring a 15-circuit vertical PCB power or signal connection. Current per circuit, the number of simultaneously loaded circuits, wire size, PCB copper area, ambient temperature, and connector temperature rise should be evaluated in the final system.
