The Diodes Incorporated DMN2400UV-7 is a dual N-channel enhancement-mode MOSFET designed to combine low on-resistance with fast switching performance. It is rated for 20V drain-source voltage and up to 1.33A continuous drain current at TA = 25°C, making it suitable for power-management functions, battery-powered systems, solid-state relays, and load switches.
At VGS = 5V and ID = 200mA, RDS(on) is 0.30Ω typical and 0.48Ω maximum. Maximum RDS(on) is 0.50Ω at VGS = 4.5V and 0.70Ω at VGS = 2.5V, enabling operation in low-voltage logic-controlled power-switching applications.
The device features a 0.5V to 0.9V gate-threshold range, only 0.5nC typical total gate charge, and 36pF typical input capacitance. Typical turn-on delay is approximately 4.06ns and rise time approximately 7.28ns, supporting efficient high-speed switching.
The DMN2400UV-7 is supplied in a compact 6-pin SOT563 package. Maximum power dissipation is 530mW, and the operating/storage junction temperature range is -55°C to +150°C. The -7 version is supplied on tape and reel with 3,000 devices per reel and carries an MSL 1 rating. It is lead-free, RoHS compliant, halogen-free, and antimony-free.
Key Features:
- Manufacturer: Diodes Incorporated
- Part Number: DMN2400UV-7
- Device Type: MOSFET
- Configuration: Dual
- Channel: N-Channel + N-Channel
- Mode: Enhancement
- Drain-Source Voltage: 20V
- Gate-Source Voltage: ±12V
- Continuous Drain Current: 1.33A @ 25°C
- Continuous Drain Current: 0.84A @ 85°C
- Pulsed Drain Current: 3A
- RDS(on): 0.48Ω Max @ VGS = 5V
- RDS(on): 0.50Ω Max @ VGS = 4.5V
- RDS(on): 0.70Ω Max @ VGS = 2.5V
- RDS(on): 0.90Ω Max @ VGS = 1.8V
- Gate Threshold Voltage: 0.5V to 0.9V
- Typical Total Gate Charge: 0.5nC
- Typical Input Capacitance: 36pF
- Typical Output Capacitance: 5.7pF
- Typical Reverse Transfer Capacitance: 4.2pF
- Maximum Power Dissipation: 530mW
- Operating / Storage Temperature: -55°C to +150°C
- ESD-Protected Gate: Yes
- Package: SOT563
- Mounting Type: Surface Mount
- MSL: Level 1
- Packaging: Tape & Reel
- Reel Quantity: 3,000 pcs
- Lead-Free / RoHS Compliant
- Halogen and Antimony Free.
