The C2012X5R1V226M125AC from TDK is a high-reliability multilayer ceramic capacitor (MLCC) designed for compact electronic circuits requiring stable capacitance, low impedance, and reliable surface-mount performance.
The capacitor provides a capacitance of 2.2µF, a rated voltage of 35V DC, and a capacitance tolerance of ±20%. It uses an X5R dielectric characteristic, offering stable capacitance performance over a wide temperature range of -55°C to +85°C.
The device features a compact 2012 inch / 0805 metric package with dimensions of approximately 2.0 × 1.25mm, making it suitable for high-density PCB layouts. The soft termination structure improves resistance against mechanical stress and board bending, enhancing reliability in demanding applications.
C2012X5R1V226M125AC is suitable for power supply filtering, decoupling circuits, DC-DC converters, consumer electronics, automotive electronics, industrial equipment, communication devices, and other applications requiring reliable MLCC performance.
Key Features
- Product type: Multilayer Ceramic Capacitor (MLCC)
- Capacitance: 2.2µF
- Rated voltage: 35V DC
- Capacitance tolerance: ±20%
- Dielectric characteristic: X5R
- Operating temperature: -55°C to +85°C
- Package size: 2012 inch / 0805 metric
- Dimensions: approximately 2.0 × 1.25mm
- Soft termination structure
- Surface mount technology (SMT)
- High reliability design
- Suitable for automotive and industrial applications
- RoHS compliant
