The LITEON LTV-1008-TP1-G is a single-channel phototransistor-output optocoupler from the LTV-10XX-G family. It integrates an infrared LED and a phototransistor to provide galvanic isolation and signal transfer between circuits operating at different electrical potentials. Typical applications include high-density hybrid substrates, programmable controllers, and general isolated interfaces.
The LTV-1008 CTR grade provides a 130% to 260% current transfer ratio at IF = 5mA, VCE = 5V, and TA = 25°C. This defined high-CTR range is useful for feedback and isolated logic-signal applications.
The device provides 5000Vrms input-to-output isolation for one minute and more than 8mm creepage distance. The phototransistor output is rated for 70V collector-emitter voltage and up to 50mA collector current.
Maximum LED forward current is 60mA, with a maximum reverse voltage of 6V. At IF = 50mA, forward voltage is 1.25V typical and 1.6V maximum. Maximum collector-emitter saturation voltage is 0.3V at IF = 10mA and IC = 1mA.
Typical rise and fall times are 3µs and 4.7µs, respectively, under the specified test conditions, with 18µs maximum limits. Typical isolation capacitance is 0.3pF, and minimum isolation resistance is 10¹²Ω.
The device operates from -55°C to +110°C and is rated for 250mW total power dissipation. It uses a 4-pin Long Mini-Flat surface-mount package. In the ordering code, TP1 identifies the tape orientation and G identifies the halogen-free option.
Key Features:
- Manufacturer: LITEON Technology
- Part Number: LTV-1008-TP1-G
- Series: LTV-10XX-G
- Device Type: Phototransistor Optocoupler
- Channels: 1
- Input Type: DC / Infrared LED
- Output Type: Phototransistor
- CTR: 130% to 260%
- CTR Test Condition: 5mA, 5V, 25°C
- Isolation Voltage: 5000Vrms
- Creepage Distance: >8mm
- Maximum LED Forward Current: 60mA
- Reverse Voltage: 6V
- Forward Voltage: 1.25V Typical, 1.6V Max
- Collector-Emitter Voltage: 70V
- Maximum Collector Current: 50mA
- Maximum VCE(sat): 0.3V
- Typical Rise Time: 3µs
- Typical Fall Time: 4.7µs
- Maximum Rise / Fall Time: 18µs
- Typical Isolation Capacitance: 0.3pF
- Minimum Isolation Resistance: 10¹²Ω
- Total Power Dissipation: 250mW
- Operating Temperature: -55°C to +110°C
- Package: 4-Pin Long Mini-Flat
- Mounting: Surface Mount
- TP1: Tape Orientation Option
- G: Halogen-Free
- Pb-Free / RoHS Compliant.
