MX34024NF1 JAE 24 Position Right Angle Pin Header Connector

MX34024NF1 JAE MX34 Series 24 Position Right Angle Pin Header Connector

The MX34024NF1 is a high-quality MX34 series board-to-cable connector developed by JAE. Featuring a 24-position configuration, 2.2mm pitch, and right-angle through-hole mounting design, this connector provides reliable electrical and mechanical performance for demanding applications.

Designed with male pin contacts and a secure locking structure, the MX34024NF1 ensures stable PCB connections and excellent resistance against vibration and environmental stress. Tin-plated contacts provide enhanced durability and long-term connection reliability.

Typical applications include:

• Automotive ECU systems
• Electric vehicle battery management systems (BMS)
• EV powertrain applications
• Industrial automation equipment
• Communication equipment
• Control modules and sensor interfaces

With JAE’s advanced connector technology, the MX34024NF1 delivers a compact and dependable interconnect solution for automotive and industrial electronics.
