The Panasonic JQ1AP-5V-F is a compact high-capacity electromechanical power relay from the Panasonic JQ series. It features a 5V DC coil and a 1 Form A (SPST-NO) normally open contact configuration, providing reliable switching for power and control circuits.
The relay offers a contact rating of 10A at 125VAC, 5A at 250VAC, and 5A at 30VDC for resistive loads. Its maximum switching power is rated at 1,250VA for AC loads and 150W for DC loads.
The 5V coil has a nominal resistance of 125Ω, a rated operating current of approximately 40mA, and nominal coil power consumption of 200mW. This makes the relay suitable for control circuits powered by common 5V logic and control supplies when used with an appropriate relay driver.
JQ1AP-5V-F uses AgSnO2-type contact material and features a sealed protective construction for improved reliability. The relay is equipped with PC board terminals for through-hole PCB mounting.
With an operating temperature range of -40°C to +70°C, high dielectric strength between the coil and contacts, and a mechanical life of at least 10 million operations, the relay is suitable for a wide range of switching and control applications.
Key Features
- Manufacturer: Panasonic Industry
- Part Number: JQ1AP-5V-F
- Panasonic Part Number: AJQ8349F
- Product Type: Electromechanical Power Relay
- Relay Series: JQ
- Coil Voltage: 5V DC
- Contact Form: 1 Form A / SPST-NO
- Contact Type: Normally Open
- Contact Capacity: Up to 10A
- Contact Rating: 10A at 125VAC
- Contact Rating: 5A at 250VAC
- Contact Rating: 5A at 30VDC
- Maximum Switching Power: 1,250VA / 150W
- Maximum Switching Voltage: 250VAC / 110VDC
- Coil Resistance: 125Ω ±10%
- Coil Current: 40mA
- Coil Power: 200mW
- Contact Material: AgSnO2 Type
- Contact Resistance: Max. 100mΩ
- Protective Construction: Sealed
- Operating Function: Single-Side Stable
- Terminal Type: PC Board Terminal
- Operate Time: Max. 20ms
- Release Time: Max. 10ms
- Mechanical Life: Minimum 10 Million Operations
- Operating Temperature: -40°C to +70°C
- Mounting Type: Through Hole / PCB
- Approximate Weight: 7g
Typical Applications
- Industrial Control Equipment
- Power Switching Circuits
- Automation Control Boards
- Home Appliances
- Power Supply Control
- Electronic Equipment
- Motor and Load Switching
- Embedded Control Systems
The JQ1AP-5V-F is suitable for designs requiring a compact 5V coil, 10A normally open PCB power relay with sealed construction and reliable switching performance.
