Renesas 2SK2225-80-E#T2 is a high-voltage N-channel power MOSFET designed for high-speed power switching applications. It features a 1500V drain-to-source voltage rating (VDSS), 2A continuous drain current, and high breakdown voltage, making it suitable for circuits that require reliable switching under high-voltage conditions.
The device has a typical RDS(on) of 9Ω and a maximum of 12Ω at ID = 1A and VGS = 15V. Its typical input capacitance is 990pF, while the gate-to-source voltage rating is ±20V. With high-speed switching characteristics and relatively low drive current requirements, the 2SK2225-80-E#T2 is suitable for a variety of industrial and consumer power switching designs.
Key Features:
- Manufacturer: Renesas Electronics
- Part Number: 2SK2225-80-E#T2
- Device Type: N-Channel Power MOSFET
- Drain-to-Source Voltage (VDSS): 1500V
- Continuous Drain Current (ID): 2A
- Peak Drain Current: 7A
- RDS(on): 9Ω typical, 12Ω maximum
- Gate-to-Source Voltage (VGSS): ±20V
- Input Capacitance (Ciss): 990pF typical
- Output Capacitance (Coss): 125pF typical
- Reverse Transfer Capacitance (Crss): 60pF typical
- Channel Dissipation: 50W
- High-speed switching
- Low drive current
- Package: TO-3PF / TO-3PFP
- Mounting Type: Through Hole
- Packaging: Tube
The device is suitable for high-voltage switching, power switching circuits, industrial equipment, consumer electronics, power supplies and other switching applications where high voltage capability and reliable switching performance are required.
