The CL10A106MO8NQNC from Samsung Electro-Mechanics is a general-purpose multilayer ceramic capacitor (MLCC) featuring a nominal capacitance of 10µF, capacitance tolerance of ±20%, and a rated voltage of 16V DC. It is suitable for power decoupling, bypass, filtering, and energy-storage functions in general electronic circuits.
The capacitor uses an X5R Class II ceramic dielectric, specified for operation from -55°C to +85°C. X5R dielectric technology provides relatively high capacitance density, making the device useful for power-rail decoupling and input/output filtering in compact electronic systems.
CL10A106MO8NQNC uses a compact 0603 inch / 1608 metric surface-mount case. Its dimensions are approximately 1.60 ±0.15mm × 0.80 ±0.15mm × 0.80 ±0.15mm, enabling 10µF capacitance in a small PCB footprint for high-density circuit designs.
The final “C” package code identifies Samsung’s standard 7-inch cardboard reel option. The series is RoHS and REACH compliant. Samsung Electro-Mechanics currently classifies the CL10A106MO8NQN# series as NRND (Not Recommended for New Design) and lists CL10A106MO8NRN# as the recommended replacement series.
Key Specifications:
- Brand: Samsung Electro-Mechanics
- Part Number: CL10A106MO8NQNC
- Product Type: Multilayer Ceramic Capacitor / MLCC
- Product Grade: General Standard
- Capacitance: 10µF
- Capacitance Tolerance: ±20%
- Rated Voltage: 16V DC
- Dielectric / TCC: X5R
- Temperature Range: -55°C to +85°C
- Case Size: 0603 / 1608 Metric
- Length: 1.60 ±0.15mm
- Width: 0.80 ±0.15mm
- Thickness: 0.80 ±0.15mm
- Mounting Type: SMD / SMT
- Construction: Multilayer Ceramic
- Package Code: C
- Reel Type: 7″ Cardboard Reel
- RoHS Compliant: Yes
- REACH Compliant: Yes
- Product Status: NRND
- Recommended Replacement Series: CL10A106MO8NRN.
