The TLV9064IPWR from Texas Instruments is a quad low-voltage CMOS operational amplifier featuring rail-to-rail input and output (RRIO) capability. It is designed for cost-sensitive systems that require low-voltage operation, compact size, good bandwidth, and reliable analog signal conditioning.
The device operates from a 1.8V to 5.5V supply and provides a typical gain-bandwidth product of 10MHz with a typical slew rate of 6.5V/µs. These characteristics make it suitable for sensor interfaces, signal conditioning, active filtering, portable electronics, and embedded analog applications.
TLV9064IPWR also features low input bias current, low offset voltage, and low power consumption. Typical quiescent current is approximately 538µA per channel, while the input bias current is typically around 0.5pA. The device is unity-gain stable and integrates RFI and EMI filtering to improve robustness in electrically noisy environments.
The amplifier is supplied in a 14-pin TSSOP (PW) surface-mount package and supports an operating temperature range of -40°C to +125°C. It is suitable for industrial electronics, battery-powered systems, sensor front ends, ADC signal conditioning, portable equipment, and general-purpose low-voltage analog circuits.
Key Features
- Quad CMOS operational amplifier
- Number of channels: 4
- Rail-to-rail input and output
- Supply voltage range: 1.8V to 5.5V
- Gain-bandwidth product: 10MHz typical
- Slew rate: 6.5V/µs typical
- Input bias current: 0.5pA typical
- Quiescent current: 538µA per channel typical
- Low input offset voltage
- Unity-gain stable
- Integrated RFI and EMI filter
- Good capacitive-load drive capability
- Operating temperature: -40°C to +125°C
- Package: 14-pin TSSOP (PW)
- Mounting type: Surface Mount
- RoHS and REACH compliant
- Product status: Active
