The Amphenol G97R22312HR is a high-speed Mini Cool Edge IO (MCIO) connector compliant with the SFF-TA-1016 interface specification. Designed for PCIe Gen 5, SAS, SFP and NVMe applications, it features 74 contacts, a 0.60 mm pitch, 85-ohm differential impedance and a right-angle surface-mount configuration. Its dual-purpose interface supports both cable and card-edge connections, providing a compact and flexible interconnect solution for servers, data centers, storage systems and high-performance computing equipment.
The G97R22312HR incorporates a high-temperature thermoplastic housing and phosphor-bronze contacts with 0.76 μm gold plating in the contact area for dependable electrical performance and corrosion resistance. It is rated for 0.5 A, operates from −40°C to +105°C and offers a durability rating of 250 mating cycles. The UL 94 V-0 flammability rating and tape-and-reel packaging make it suitable for automated SMT assembly and high-volume production.
