The 5025985193 from Molex is an Easy-On 502598 Series FPC connector featuring a 0.30 mm pitch and 51 circuits for compact, high-density interconnect applications. Its Back Flip actuator simplifies FPC insertion and locking, while the dual-contact configuration provides a reliable connection between the flexible circuit and PCB.
The connector features a right-angle surface-mount design with a low 1.15 mm mated height, helping reduce overall PCB assembly height. Its contacts are made of phosphor bronze with gold plating for dependable electrical contact performance. The connector is designed for FPC use and supports up to 10 mating cycles.
The 5025985193 is rated for up to 0.3A per contact and 50V, with an operating temperature range of -40°C to +105°C. It is supplied in embossed tape-on-reel packaging for automated SMT assembly and complies with applicable EU RoHS and low-halogen requirements.
Its ultra-fine pitch, high circuit count and low-profile construction make it suitable for consumer electronics, portable devices, display modules, camera modules and other space-constrained FPC-to-PCB interconnect applications.
Key Specifications:
- Brand: Molex
- Part Number: 5025985193
- Series: Easy-On 502598
- Product Type: FFC / FPC Connector
- Cable Type: FPC
- Number of Circuits: 51
- Pitch: 0.30 mm
- Actuator Type: Back Flip
- Contact Style: Dual Contact
- Orientation: Right Angle
- PCB Mounting: Surface Mount
- Mated Height: 1.15 mm
- Maximum Current per Contact: 0.3A
- Maximum Voltage: 50V
- Contact Material: Phosphor Bronze
- Contact Plating: Gold
- Maximum Mating Cycles: 10
- Operating Temperature: -40°C to +105°C
- Packaging: Embossed Tape on Reel
- RoHS: Compliant
- Low-Halogen: IEC 61249-2-21 compliant
