The STM32L162RET6 from STMicroelectronics is an ultra-low-power 32-bit microcontroller from the STM32L1 family. It is based on an Arm Cortex-M3 core operating at up to 32MHz, delivering approximately 33.3 DMIPS maximum processing performance for low-power industrial, portable, and embedded-control applications.
The device integrates 512KB of embedded Flash, 80KB of SRAM, and 16KB of true data EEPROM. The Flash is arranged as two 256KB banks with Read-While-Write capability and ECC, while the EEPROM provides nonvolatile storage for parameters, calibration information, and system configuration.
Integrated security and system features include an AES-128 hardware encryption accelerator, CRC calculation unit, 96-bit unique device ID, and a Memory Protection Unit within the Cortex-M3 core. These resources support device identification, data integrity, and embedded security functions.
Analog peripherals include a 12-bit 1Msps ADC, two 12-bit DAC channels, two operational amplifiers, and two ultra-low-power comparators. The ADC supports up to 40 channels across the STM32L162xE device family for sensor acquisition and analog-control applications.
Communication interfaces include USB 2.0, up to five USART/UART interfaces, three SPI interfaces, two I²S interfaces, and two I²C interfaces with SMBus and PMBus compatibility. DMA, 16-bit and 32-bit timers, and independent and window watchdogs are also integrated.
An integrated LCD controller can drive up to 8 × 40 LCD segments and includes an internal LCD voltage generator, contrast adjustment, and blinking capability. Up to 34 capacitive-sensing channels are also available for implementing touch keys, sliders, and basic touch interfaces.
The STM32L162 platform is optimized for low-power operation and can operate from supplies down to approximately 1.65V, depending on brownout-reset configuration. ST specifies typical power figures including 290nA Standby current, 560nA Stop current, and approximately 195μA/MHz in Run mode.
The STM32L162RET6 is supplied in a 64-pin LQFP package measuring 10 × 10 × 1.4mm and is classified as an industrial-grade product. ST currently lists the exact orderable part as Active and in volume production.
Key Specifications
- Manufacturer: STMicroelectronics
- Manufacturer Part Number: STM32L162RET6
- Product Family: STM32L1 / STM32L162
- Device Type: Ultra-Low-Power 32-Bit MCU
- CPU Core: Arm Cortex-M3
- Maximum CPU Frequency: 32MHz
- Maximum Performance: Approximately 33.3 DMIPS
- Flash Memory: 512KB
- Flash Banks: 2 × 256KB
- SRAM: 80KB
- Data EEPROM: 16KB
- Hardware Encryption: AES-128
- CRC Unit: Integrated
- Unique Device ID: 96 Bits
- MPU: Supported
- ADC: 12-Bit, Up to 1Msps
- ADC Channels: Up to 40
- DAC: 2 × 12-Bit
- Operational Amplifiers: 2
- Ultra-Low-Power Comparators: 2
- LCD Controller: Up to 8 × 40 Segments
- Capacitive Sensing: Up to 34 Channels
- USB: USB 2.0
- USART: Up to 3
- UART: Up to 2
- SPI: Up to 3
- I²S: Up to 2
- I²C: 2
- SMBus / PMBus: Supported
- DMA Channels: 12
- 32-Bit Timers: 1
- 16-Bit Timers: Multiple
- Watchdogs: Independent and Window
- RTC: Integrated
- Supply Voltage: Approximately 1.65V to 3.6V Depending on BOR Configuration
- Typical Standby Current: 290nA
- Typical Stop Current: 560nA
- Typical Run Consumption: 195μA/MHz
- Wake-Up Time: Approximately 8μs
- Debug Support: SWD, JTAG, and Trace
- Bootloader: USB and USART Support
- Package: LQFP-64
- Package Size: 10 × 10 × 1.4mm
- Product Grade: Industrial
- RoHS Grade: Ecopack2
- Product Status: Active / Volume Production
Typical Applications
Suitable for low-power industrial controllers, portable instrumentation, smart metering, data-acquisition systems, sensor nodes, medical electronics, battery-powered equipment, LCD-based interfaces, and embedded systems requiring integrated USB, analog peripherals, EEPROM, and ultra-low-power operating modes.
Can STM32L152RET6 replace STM32L162RET6 when the firmware uses AES?
Check whether the firmware calls the hardware AES peripheral. ST’s shared reference manual assigns that peripheral to STM32L162xx devices. STM32L162RET6 and STM32L152RET6 both use a 64-pin LQFP, so confirm AES usage before approving a substitution. STMicroelectronics reference manual and STMicroelectronics product documentation.
